AM844D

8-MIC, 4-STEREO LINE 4-GROUP MIXER WITH DFX

8 Mic/Line mono channels with direct outs, 3-band EQ and compressor
4 stereo channels (two with Mic input)
10 Mic preamps total
Direct Outputs for multi-track recording
3-band EQ with swept-mid range plus low cut on each mono channel
18dB/oct, 75Hz Low Cut Filter on each mic channels
4 AUX sends, AUX 1 & 2 with Pre/Post selector
32/40-bit digital stereo effect processor with 16 programs
4 stereo AUX Returns
Solo selector on each input channel
CTRL RM Phones with multi input source matrix selector
8 Subgroups with Fader control and L-R assign buttons
Stereo RCA Record Outputs
2T return with control level and TO MAIN L/R assign button
Built-in switching power supply with universal connector, 100-240VAC, 50/60Hz
12V XLR Connector for gooseneck lamp
Solo switch selector for AUX Returns

The AM series mixers are compact and versatile with anywhere between 5 and 24 mono mic/line and stereo inputs. Ultra low noise pre-amps ensure high quality sound when used in project studios or sound reinforcement. Low-cut filters on mono channels eliminate unwanted sounds like stage rumble, P-pops, wind noise and low frequency recording studio room resonances. The multi-band EQ on mono channels gives you total control over your mix. The AM series also makes monitoring the mix easy with its dual multi-segment LED level meters and high volume headphone outputs.

Download

AM844D Datasheet English
AM844D Manual (English+Spanish)
