Digital Matrix Amplifiers

PHONIC introduces the DMA series digital matrix amplifiers – combining smart signal processing with a flexible modular mixing matrix and robust amplification. Sound complex? It’s not, because all routing and processing is adjusted through the simple yet intuitive software. The DMA series provides racks-full-o-gear in a modest 2U construct. Combining many great products into a simple design, the DMA series simplifies your installation and saves you money. Whether designing or installing systems in auditoriums, restaurants, houses of worship, boardrooms, courtrooms or performance spaces, PHONIC has a DMA matrix amplifier that will fit your exact requirements.

DMA8813 / DMA8813D

8x8 1040 Watt Digital Matrix Amplifier
8-channel amplifier – 130 watts per channel
4 ohm and constant voltage models available(70V or 100V)

NT2508 / NT2508D

8x8 2000 Watt Digital Matrix Amplifier
8-channel amplifier – 250 watts per channel
4 ohm and constant voltage models available(70V or 100V)

Power OutputPer ChannelDante
8Ω / 4Ω70V/100V
DMA8413 (8x4) 80W / 130W130WOptional
DMA8425 (8x4) 150W / 250W250WOptional
DMA8813 (8x8)80W / 130W130WOptional
DMA8825 (8x8)150W / 250W250WOptional

8-in x 8-out sophisticated matrix mixing makes routing easy
8 built-in mic preamplifiers
Dual RCA and balanced euroblock inputs
Stereo RCA inputs summed to mono
Eight 2-pin euroblock speaker outputs
Stand-alone control possible with monitor and mouse with VGA and USB connectors
Remote user control through PC software
SD card slot for audio playback
44.1 kHz or 48kHz sample rate
24-bit A/D D/A conversion

DSP Processing:
• Automatic Mixing
• Compressor/Limiter • Feedback Silencer
• 4-band EQs
• Crossover
• Automatic level Control
• Program Intuitive Ducker
+48V phantom power
AES / EBU input and output
Word Clock input and output
Event scheduling

External control via Asystems RM series wall remote
Scene recall feature for recalling all system settings
Password protected user accounts
Signal generator (white noise, pink noise, sine wave, etc)
Real-time error notifications via email reporting function
DMA8813D and DMA8825D
feature 8x8 Dante Expansion option

System Example: Department Store
System Example: Public Parking Lot
Brand URL : DMA8825D
